Tadano AML-C User Manual

Chapter A Chapter A
Components of AML System
15
W301-0411E
CN2-2 connector SW status in AML
Pin No. Name
(Data No. #---)
Signal names and functions
ON (0) OFF (1)
12 Di28+
(#17202-36)
- Signal name: Twoblocking detection
Detects the twoblocking.
Not
twoblocking
Twoblocking
13 FG Frame ground (Connected with ground on circuit board)
14 PSRC (Spare)
15 P2B
Signal name: Drum indicator input (Aux.)
Detects the rotation of auxiliary winch drum.
16 P1B
Signal name: Drum indicator input (Main)
Detects the rotation of main winch drum.
