TRM-AZION: Inverter + elevation motor cable
Download board - Inverter
Inverter Signal Color Elevation board
X5
5 Input signal reference -
Input signal reference
White
-
6
Input signal reference White 1
15 Direction control Brown 2
35 Enable motor movement Green 3
18 Pulses Yellow 5
3 Belt motor thermal cutout Gray 6
17 Limit switch state Pink 7
Output signal reference Blue 8
7
- Output signal reference
Blue
-
13
-
34
Output signal reference
Blue
-
Inverter Signal Color Download Board
XLNK
27 Link + Red 2
28 Link - Black 1
Patch
G
Signal Color Elevation board
X2
1 Mot+ Brown 1
2 Mot- Blue 2
4 Gnd White-Yellow 4
5 +5 Vdc power supply Yellow-Brown 5
6 Pulses White-Gray 6
Patch
H
Signal Color Inverter Elevation
board
X6
1 Gnd White-Green - 2
2 Out 1 Red-Blue 10
Gray-Pink -
3
Gray-Pink 9
1
- 9 -
-
+5 Vdc power supply
Gray-Pink
11 -
4 Out 2 Purple 12 -
