RUN EXCITE: Service & Maintenance Manual - rev. 1.5
TRM-48: Inlet DVD video cable
Connectors board – AUX input board
Connectors
board
CN1
Signal Color AUX input
board
J4
1 Color Red 1
2 Left audio IN White 2
3 Gnd Shield 3
4 Right audio IN Red 4
5 Gnd Shield 5
6 Video IN Yellow 6
7 Gnd Shield 7
8 Commutation White 8
TRM-49: Inlet CD cable
Connectors board – AUX input board
Connectors
board
CN15
Signal Color AUX input
board
J1
1 Right audio IN Red 1
2 Gnd Shield 2
3 Left audio IN White 3
4 Gnd Shield 4
TRM-50: 110V power supply cable
Patch conn. Q – Patch conn. R - Filter
Patch conn.
Q
Signal Color P.E. Patch conn.
R
Filter
terminal
1 Gnd Giallo/verde Eyelet - -
2 Fase 110V Marrone - 1 -
3 Neutro 110V Blu - 2 -
4 Fase 220V Marrone - - N
5 Neutro 110V Blu - P
CV-281: LCD inverter power supply cable
CPU board – LCD inverter
CPU board
CN5
Signal Color LCD inverter
CN1
1 +12 Vdc power supply Black 11
2 Reference Black 2
3 +3.3 Vdc power supply Black 4
4 Reference Black 3
5 +12 Vdc power supply Black 12
Page 2.25
