Technogym Run Excite 700 - Page 36

RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 2.24
TRM-38: Motor compartment fan cable (extension)
Power supply board – Patch connectors - Inverter
Power supply
board
XV2
Signal Color Inverter Patch
P
Patch
L
1 24 Vdc power supply White 32 - -
- - Red 31 1 1
2 Gnd Black - 2 2
TRM-42: Download board power supply cable
Power supply board – Download Board
Power supply
board
XV5
Signal Color Download Board
XALE
2 +5 Vdc power supply for display Red 1
3 Gnd Black 2
TRM-43: Inverter Serial Cable
Download board - Inverter
Download Board
XPRG2
Signal Color Inverter
1 Digital #1 Flat cable 1
… … … …
14 Digital #14 Flat cable 14
TRM-44: Power supply LED cable
Power supply board - LED
Power supply
board
CN1
Signal Color LED
3 +12 Vdc Green
4 +12 Vdc reference Yellow
12V LED
Green
7 +5 Vdc Gray
8 +5 Vdc reference Pink
5V LED
Green
9 +24 Vdc reference White
10 +24 Vdc Brown
24V LED
Green
