RUN EXCITE: Service & Maintenance Manual - rev. 1.5
TRM-36: Belt motor + Limit switch cable
Patch connectors – Belt motor – Limit switch
Patch
I
Signal Color Inverter Elevation
board
X3
1 U Brown U -
2 V White V -
3 W Black W -
4 Thermal cutout + Red - 4
5 Thermal cutout - Red - 3
6 Gnd Gray PE -
Patch
M
Signal Color Inverter Elevation
board
X3
1 Limit switch contact Brown - 5
2 Limit switch contact reference White - 6
TRM-36A: Belt motor (UL)
Patch connectors – Inverter – Elevation board – Power supply board
Patch
I
Signal Color Inverter Elevation
board
X9
1 V Brown V -
2 U White U -
3 W Black W -
4 Thermal cutout + Red - 4
5 Thermal cutout - Red - 3
6 Gnd Gray PE -
Power supply
board
XE
Signal Color Inverter Elevation
board
X9
2 Vdc reference Black - 2
1 +15 Vdc power supply White - 1
TRM-36B: Limit switch cable (UL)
Elevation board – Patch connectors
Elevation
board
X3
Signal Color Patch
M
5 Limit switch contact Brown 1
6 Limit switch contact reference White 2
Page 2.23
