RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 2.22
TRM-28/B: OwnZone receiver cable
Patch connectors – OwnZone Receiver
OwnZone
Receiver
CN1
Signal Color Patch
O
Patch
N
1 I2C clock Blue - 1
2 I2C data Green - 2
3 Pulse (beat to beat) Brown 4 -
4 Power supply White 2 -
5 Gnd Yellow 1 -
9 External Reset Orange 3 -
TRM-29: Joystick cable
Digital Plan Board - Microswitch
Digital Plan
Board
CN16 or CN17
Signal Color Micro + Micro -
1 Value 1 reference White - C
2 Value 1 (incline or speed -) Brown - NO
3 Value 2 reference Green C -
4 Value 2 (incline or speed +) Yellow NO -
TRM-31: CSafe cable board
Digital Plan Board – CSafe Board
Digital Plan
Board
CN15
Signal Color CSafe Board
CN1
1 Digital #1 Flat cable 1
… … … …
14 Digital #14 Flat cable 14
TRM-32: TGS/smart card Cable
Digital Plan Board – TGS/Smart Card Board
Digital Plan
Board
CN10
Signal Color TGS/Smart Card
Board
CN1
1 +12 Vdc power supply Yellow 1
3 Rx White 8
5 Tx Green 7
9 Gnd Brown 3
