Technogym Step 700i E - D Isassembling the Power Entry Module and the Wheels

STEP EXCITE: Service & maintenance manual - rev. 1.4
Page 7.41
7.17. DISASSEMBLING THE POWER ENTRY MODULE AND
THE WHEELS
Figure 7.17-1
Turn the machine over on one side.
To remove the wheels:
1. Back off the screws a using a small Phillips
screwdriver.
2. Remove the wheels group.
To remove the power entry module:
1. Back off the screws b using a small Phillips
screwdriver.
2. Remove the power entry module plate
covering.
Figure 7.17-2
3. Back off the two screws c using a medium
Phillips screwdriver and remove the power
entry module.
4. Disconnect the cable d from the power entry
module.
5. Remove the power entry module.
