STEP EXCITE: Service & maintenance manual - rev. 1.4
Page 2.15
2.8. WIRING
CB-9: DVD video input cable
Connector board - AUX input board
Connector board
CN1
Signal Color Input board
J1
1 Color Red 1
2 left audio IN White 2
3 Gnd Braid 3
4 right audio IN Red 4
5 Gnd Braid 5
6 video IN Yellow 6
7 Gnd Braid 7
8 Switching White 8
CBQ-13: CSafe board cable;
Display Board – CSafe Board
Display Board
CN8
Signal Color CSafe Board;
CN1
1 Digital #1 Flat cable 1
… … … …
14 Digital #14 Flat cable 14
CBQ-25-1: Hand sensor board cable
Display Board – Hand Sensor Board
Display Board
CN4
Signal Color Hand sensor
board
J3
1 +5 Vdc power supply Red 2
5 Pulse out Blue 3
6 Reference Black 1
CBQ-32: TGS Cable
Display Board – TGS reader
Display Board
CN7
Signal Color TGS reader;
CN1
1 +12 Vdc power supply Yellow 1
3 Rx White 8
5 Tx Green 7
9 Gnd Brown 3
