STEP EXCITE: Service & maintenance manual - rev. 1.4
Page 10.3
10.3. TWICE-YEARLY MAINTENANCE OPERATIONS
These operations can only be carried out by a qualified technician specifically trained by
Technogym and authorized to carry out machine installation and adjustments, as well as
special maintenance operations or repairs which require special knowledge of the
machine, its operation, safety systems and working procedures.
The twice-yearly maintenance operations involve checking the functioning, wear and tension of the
mechanical components so as to ensure the correct and safe operation of the machine.
For the twice-yearly maintenance of the machine, proceed as follows:
10.3.1. CARRYING OUT THE MONTHLY MAINTENANCE PROCEDURE
1. Carry out the procedure described in paragraph 10.2. “Monthly maintenance operations”.
10.3.2. SETTING UP THE OPERATION
Only for 500i, 700i and 700i E models.
1. Turn off the machine by placing the switch in position 0 (OFF).
2. Unplug the mains lead from the wall outlet.
10.3.3. CHECKING THE WORKING CONDITIONS
Only for 500i, 700i and 700i E models.
1. Using a multimeter, check that the machine earth node is correctly connected to earth.
10.3.4. CHECKING THE WEAR OF RUBBER PARTS
1. Check the state of wear of the rubber components. Replace if there are evident signs of wear.
10.3.5. CHECKING THE BELT
1. Check the state of wear of the belt, using the pulley to turn it by hand, paying special attention
to the edges and the inner part. Replace if there are evident signs of wear.
2. Also check the tension of the belts.
10.3.6. CHECKING THE CHAINS
1. Check the state of wear of the pedal chains and primary shaft chain, in particular checking for
any links that are jammed and/or have excessive play. Replace if it shows evident signs of wear.
2. Check the tension of the primary shaft chain. Adjust the tension if necessary.
3. Lubricate the pedal chains and the primary shaft chain with chain spray grease that comes with
the service box. After lubricating, move the pedals up and down a few times.
10.3.7. CHECKING THE WEAR OF THE PULLEYS
1. Check the state of wear of the pulleys. Replace if they show evident signs of wear.
