STEP EXCITE: Service & maintenance manual - rev. 1.4
Page 2.18
STP-06: Hand sensor – Touch sensor cable
Hand Sensor Board - Sensors
Hand sensor
board
Sensors
J2 - J4
Signal Color
Right Left
1 Right sensor signal White up -
2 Sensor signal reference Brown down -
3 Gnd Black - -
4 Left sensor signal White - up
5 Sensor signal reference Brown - down
6 Gnd Yellow/green - -
Display board – Touch sensor
Display board
CN5 / CN6
Signal Color Touch sensor
1 + 5Vdc White 1
2 Button Brown 3
4 Reference Green 4
