STEP EXCITE: Service & maintenance manual - rev. 1.4
Page 6.9
6.2.3. 700I E MODEL WITH WELLNESS TV
Does the wall outlet supply the
correct v oltage?
Is the mains lead OK?
Is the voltage at the
output of the machine's
power entry module
correct?
Plug the machine into a
working electrical outlet
Replace the mains lead
Replace the power
entry module on the
machine
THE DISPLAY
DOES NOT
ILLUMINATE
Does the mains v oltage
reach the input to the
brake board?
NO
YES
NO
YES
NO
YES
NO
YES
2
A
Replace cable STP-00
1
Are the the fuses OK ?
Replace the f uses
NO
YES
Continued on the following page.
