Oscilloscope Reference Measurement menu
Behavior
This list contains your selected automatic measurements. You can add up to eight automatic measurements
to the list. The measurements appear on the main screen when the Display button is On.
When you click Clear without selecting a measurement, the last measurement in the list is d eleted.
TIP. To quickly move the measurements from one channel to another, select all of the measurements
in the list (click the first measurement, hold the left mouse button, and drag the mouse to the last
measuremen
t), and then select a new channel from the Source control. Similarly, you can change all of
the measurements from one type to another if you select all the measurements in the list and click on a
single measurement button.
What do you want to do next?
Learn mo
re about the Measurement controls.
(see page 286)
Return to the Measurement Setup control window overview. (see page 268)
Measurement menu
Use Measurement menu commands to select from and set up a variety of automatic measurements.
Commandsarealsoavailableonthismenuforfurtherin-depth analysis, gating (bounding), statistics,
comm
unication, and histograms.
Mid2 reference
The Mid2 reference defines the middle reference used on the second waveform speci fi ed in delay or phase
me
asurements; the default level is 50%. To change this level, click the control, and then set the level
with the multipurpose knob.
M
id reference
T
he Mid reference defines the middle reference level of a waveform; the default level is 50%. This
reference value is primarily used for making measurements between edges such as pulse widths. To
change this level, click the control, and then set the level with the multipurpose knob.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 871
