Textron Jacobsen 600 Series User Manual

HYDRAULICS
8C-10
Table 8C-5: Replacement O-Ring for ORS Fittings Table 8C-6: O-Ring Face Seal Torque
Recommendations
ORS Tube Size
ORS O-Ring
Size
Jacobsen
Part No.
4 11 339908
6 12 339909
8 14 339910
10 16 339911
12 18 339912
16 21 339913
20 25 339914
24 29 339915
SAE Dash
Size
Thread
Size
Tube O.D.
Torque
In-lbs
3N/AN/A
4 9/16 0.250 120-144
5N/AN/A
6 11/16 0.375 216-240
8 13/16 0.500 384-420
10 1-14 0.625 552-600
12 1 3/16-12 0.750 780-840
16 1 7/16-12 1.000 1104-1200
20 1 11/16-12 1.250 1500-1680
24 2-12 1.500 1800-3960
