Power-over- Ethernet (POE) TCP/IP Receiver
66 Administrator Guide v 2.2 Thermo Scientific Smart-Vue
®
Wireless Monitoring Solution
13.4.1 Smart-Vue PoE
Network Receiver
A PoE network receiver:
• Collects data transmitted by end-point modules and forwards it via a
receiver module to the Smart-Vue Server database (from which users
manage and access their end-point modules transparently using
Smart-Vue Client software)
• Transmits configuration and on-demand read requests from the client
software to end-modules
• Includes a 10/100BT RJ-45 port
• Has a range from 25-100 meters (65-325 ft.) indoors up to
approximately 700 meters (2,300 ft.) in line of sight
• Supports a nearly unlimited number of end-point modules
Ethernet port LEDs
The receiver’s Ethernet port has two LEDs,
Figure 37. Ethernet port LEDs indicate connection status
Network link
Green: 100 Mbps
Orange: 10 Mbps
Network activity
