PT100 Module (External Sensor)
26 Administrator Guide v 2.2 Thermo Scientific Smart-Vue
®
Wireless Monitoring Solution
Figure 14. PT100 sensor details (blue band  standard)
Figure 15. PT100 sensor details (yellow band  cryogenic)
4.4 Where to Find More
Information
The Smart-Vue Software User Manual provides detailed information on
module and system configuration. You may click on Help  User manual
( ) to open the software user manual directly from within the Smart-Vue
Client software.
Male
connector
Blue thermo-retractable band
Shielded cable
Thermo-retractable
band
Steel tube
Sensor
Male
connector
Yellow thermo-retractable
band
Shielded cable
Junction pot
Steel tube
Sensor
