103
16. SETTING-OUT LINE
(2) Line: Distance along the
baseline from the first point to
the position at which a line
extending from the required
point intersects the baseline at
right angles (X direction).
(3) Offset: Distance from the
required point to the position
at which a line extending from
the required point intersects
the baseline at right angles (Y
direction).
• []/[]: Press to decrease/
increase the value by the
amount set in "Incr".
3. Press [OK] on the screen of step
2. The coordinate value of the
required point is calculated and
displayed.
• [REC]: records the coordinate
value as a known point data.
Recording method:
"30.1 Registering/Deleting
Known Point Data"
•Press [S-O] to move to setting-
out measurement of the required
point.
"15. SETTING-OUT
MEASUREMENT"
4. Press {ESC}. Continue the
measurement (repeat steps from
2).
Set-out line
12.024
94.675
N
E
Z
111.796
REC S-O
