201
25. ROUTE SURVEYING
• When curve properties are already
input, curve type cannot be changed.
First clear all route data.
"25.8.2 Inputting Curve Elements"
The automatic setting method can be selected from the following:
(*: Factory setting)
・ BP Point of the next curve: "IP" (IP Point of the previous curve)*/"EC/KA2"
(end-point of the previous curve (KA-2 or EC Point)).
• Curve: Clothoid* / Parabola
Alignment/Setting
Next BP : IP
Existing curve
Curve : Clothoid
