13. SETTING INSTRUMENT STATION
82
7. If measuring two or more known
points, repeat procedures 4 to 6 in
the same way from the second
point.
•Press {ESC} to return to the
previous known point.
8. Press [CALC] to automatically
start calculations after
observations of all known points
are completed. Instrument station
elevation and standard deviation,
which describes the measurement
accuracy, are displayed.
9. Press [RESULT] to check the
result.
If there are no problems in the
result, press {ESC} and go to step
10.
10. If there are problems with the
results of a point, align the cursor
with that point and press [OMIT].
“*” is displayed on the left of the
point.
11. Press [RE_CALC] to perform
calculation again without the point
designated in step 10. The result
is displayed.
If there are no problems with the
result, go to step 12.
If problems with the result occur
again, perform the resection
measurement from step 4.
12. Press [OK] to finish resection
measurement. Only Z (elevation)
of the instrument station
coordinate is set. N and E values
are not overwritten.
Z
Z
10.000
0.0022m
RESULT
OK
1st
2nd
3rd
0.000
-0.003
-0.003
4th
0.002
Z
RE
_
CALC
OMIT
RE
_
MEAS
ADD
