- 67 -
KOR
Reads the current correction factor setting from the SR-LEDW/SR-UL2/SR-
UL1R/SR-3AR.
KOR1:Reads out whether the current correction factor setting for spectrum is
the enable/disable state.
KOR2: Reads out whether the current correction factor setting for tristimulus
value is the enable/disable state.
1: Enable 0: Disable
CIE_#
Change the CIE Color Matching function (visual field) setting.
For the pound sign (#), use 0 for a visual field and 1 for a 10° visual field.
CIER
Reads the CIE Color Matching function (visual field) setting.
LDF#
Changes the luminance display format setting.
For the pound sign (#), use 0 for decimal and 1 for exponencial.
LDFR
Reads the luminance display format setting.
LDD_#_#
Sets the number of display digits for the luminance display format.
Use 10 to 6 for the first pound sign (#) for the integer portion of the number and 0
to 3 for the second pound sign for the decimal portion.
LDDR
Reads the setting for the number of digits in the luminance display format.
FLD1
Changes the measuring field to the 2.0 position.
FLD2
Changes the measuring field to the 1.0 position.
FLD3
Changes the measuring field to the 0.2 position.
FLD4
Changes the measuring field to the 0.1 position.
FLDR
Reads the current measuring field setting.
NL_####
Integral time delay function: Input the delay time.
ND
Integral time delay function: ON
NF
Integral time delay function: OFF
HS
Sets the measuring speed to the high speed
HS2
Sets the measuring speed to the high speed 2
HS3
Sets the measuring speed to the high speed 3
NS
Sets the measuring speed to the normal speed
HCL
Start the calibration in High Speed mode
Perform the calibration when select High Speed mode.
HSR
Reads the current measuring speed mode.
Response to the HSR command
0:High speed 1:Normal speed 2:High speed 2 3:High speed 3
WHO
Reads the name of the luminance meter.
SRL
Reads the manufacturing number.
VER
Reads the program version.
FX
Starts the measurement to calculate optimum inner-filter and integral time setting
in FIX mode. When the measurement complete, the optimum inner-filter type and
integral time is retuned and the values are also set on the instrument.
(SR-LEDW only
FO
Sets to FIX INTEG modeSR-LEDW only
FG
Reads current FIX INTEG mode settingSR-LEDW only
FS_###_#
Sets inner-filter type and integral time in FIX INTEG mode. (SR-LEDW only
The left side of # means integral time[ms](50 -120,000), right side means inner-
filter (1 - 5)
FXQ_###_#
Set the measurement mode to FIX FREQ mode and inner-filter type, frequency
in FIX FREQ mode.
The left side of # means frequency [Hz](1.5 -250), right side means inner-filter
(1 3 or 5)
