153
INDIVIDUAL OPERATIONS
9 Make sure the CORNEA DIAMETER screen is on.
10 Press the MOVE LEFT POSITIONING BAR button (move to the left) or
(move to the right) and bring the left positioning bar to the left end of iris.
11 Press the MOVE RIGHT POSITIONING BAR button (move to the left) or
(move to the right) and bring the right positioning bar to the right end of iris.
12 Press ; the cornea diameter is displayed.
13 Press the , and measure the left eye in the same way.
To select screens between the saved right and left eyes, press the .
(If you save the screen of one eye only, you can not select the screen.)
To exit the mode during a measurement, press the .
The cornea diameter measurement is not possible under REF mode.
MEASUREMENT switch
MEASUREMENT switch
R/L button
PRINT button
