5. SYSTEM MODE EO18-33027
5.3 DIAG
5-21
5.3.2.1 AUTO SELF DIAG. PRINT PRINTOUT
Print condition:
Label length
120 mm
Print method
Setting by user
Sensor type
None
Speed
(203 dpi)
B-EX4T1-G, B-EX4T2-G, B-
EX6T2-G, B-
EX4D2-G
6 ips
(300 dpi/305 dpi)
B-EX4T1-T, B-EX4T2-T, B-
EX6T2-T, B-EX4D2-T
5 ips
(600 dpi)
B-EX4T2-H
3 ips
Issuing number
1
Issuing mode
User setting
Other
No Rewinder motor activated.
(*1) “°” (degree) of “xx°C” may not be printed correctly, depend on the type of code page.
(*2) The Basic program file name and system mode program file name are printed.
When the first 4 characters of each program file name are “Z-EX”, the checksum will be also printed.
PROGRAM B-EX4T1-T
MAIN XXXXXXXXX V1.0A:1A00
BOOT XXXXXXXXX V1.0 :8500
WMON XXXXXXXXX V1.0 :6100
FONT 5600
KANJI NONE :0000
NONE :0000
EEPROM 256B
SDRAM 32MB
SENSOR1 00000000,00000111
SENSOR2 [H]23 C [A]22 C
[R]4.2V [T]2.5V [E]0.6V
PE LV. [R]1.8V [T]2.5V
M THRE. [R]1.8V [T]2.5V
HEAD [RANK]7 305DPI
LAN MAC 11-22-33-44-55-66
EXP.I/O NG
EX.232C NG
RFID OK #00RV972 (EU0) R01
WLAN OK Ver1.1.3
MAC 00-11-22-33-44-55
RTC NG
USB MEMORY NG
BASIC M Z-EX4-MV10F. V1.0F:7479
BASIC S Z-EX4-SV10E. V1.0E:AD36
PROGRAM B-EX4T1-T
MAIN XXXXXXXXX C1.1A:F300
BOOT XXXXXXXXX V1.0A :0100
WMON XXXXXXXXX V1.0 :6100
FONT AE00
KANJI NONE :0000
NONE :0000
EEPROM 256B
SDRAM 32MB
SENSOR1 00000000,00000111
SENSOR2 [H]23 C [A]22 C
[R]4.2V [T]2.5V [E]0.6V
PE LV. [R]1.8V [T]2.5V
M THRE. [R]1.8V [T]2.5V
HEAD [RANK]7 305DPI
LAN MAC 11-22-33-44-55-66
EXP.I/O NG
EX.232C NG
SIO NG(0111)
RFID OK #00RV972 (EU0) R01
WLAN OK Ver1.1.3
MAC 00-11-22-33-44-55
RTC NG
USB MEMORY NG
BASIC M Z-EX4T1M13 V1.3:02DC
BASIC S Z-EX4T1S11 V1.1:BF1E
<Printout for the models supporting SIO>
B-EX4T1-TS25-R V2.0 or later
B-EX4T1-G/T C1.1A or later
B-EX4T2-G/T C1.1 or later
B-EX4T2-H C1.1A or later
B-EX4D2-G/T D1.1 or later
