Toshiba B-EX4 SERIES Service Manual

6. ON LINE MODE EO18-33027
6.1 KEY FUNCTION
6-2
6.1.2 Help Display
Key
Function
[FEED]
(1) Ends help display.
[RESTART]
(1) Ends help display.
[PAUSE]
(1) Ends help display.
[MODE]
(1) Ends help display.
[CANCEL]
(1) Ends help display.
(2) Returns to the previous help page.
(3) Ends help display.
[ENTER]
(1) Ends help display.
(2) Goes to the next help page.
(3) Ends help display.
[UP]
(1) Moves the cursor upward.
[DOWN]
(1) Moves the cursor downward.
[LEFT]
(1) Returns to the previous help page.
(2) Ends help display.
[RIGHT]
(1) Goes to the next help page.
(2) Ends help display.
6.1.3 Manual Threshold Setting Display
Key
Function
[FEED]
(1) Moves the cursor upward.
(2) Re-sets
[RESTART]
(1) Moves the cursor downward.
[PAUSE]
(1) Sets the threshold.
(2) Fixes the selection.
[MODE]
No function.
[CANCEL]
No function.
[ENTER]
(1) Fixes the selection.
(2) Ends manual threshold setting.
[UP]
(1) Moves the cursor upward.
[DOWN]
(1) Moves the cursor downward.
[LEFT]
(1) Goes to the judgment result page
(2) Goes to the fine adjustment setting menu
[RIGHT]
(1) Goes to the detail page.
(2) Goes to the fine adjustment setting menu

Toshiba B-EX4 SERIES Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
Max Print Width	104 mm
Connectivity	USB, Serial, Ethernet
Media Sensor	Transmissive, Reflective
Media Type	Roll, Fanfold, Tag, Ticket
Media Width	25.4 mm
Ribbon Width	110 mm
Ribbon Length	Up to 600 m
Media Thickness	0.06 – 0.19 mm
