6. ON LINE MODE EO18-33027
6. 8 INFORMATION MODE
6-19
6.8 INFORMATION MODE
6.8.1 Outline of the Information Mode
In the information mode, the total feed amount counted during feed and printing operations is
displayed on the LCD, and printed in units of centimeter and inch on request.
The feed amount is counted at the end of feed or printing, and saved in the non-volatile memory.
NOTES:
1. The effective range of the feed amount
(*1)
is as follows. When the feed amount exceeds the
maximum, the maximum value will be saved.
In unit of centimeter: 0 to 320000000
In unit of inch: 0.0 to 125984251.9
2. In the following cases, feed or printing is not counted in this feed amount
(*1)
.
Reverse feed, Forward feed to the strip position, Pre-strip feed, Auto forward feed, Void printing
on RFID media, RFID tag position adjustment command (@003 command), Pre-reverse feed
when an expansion I/O device is connected, Printing in offline (Diag. test print, maintenance
counter print, test print, dump), printing in the information mode, manual threshold, automatic
calibration, and RFID calibration
3. Since the feed amount
(*1)
is counted based on the label pitch specified by the command, a large
margin of error may be generated if the command-specified label pitch differs from the actually-
measured label pitch.
4. Since the counted feed amount is saved in the non-volatile memory (EEPROM), replacement of
the EEPROM is prohibited. (Except for the case the Main PC board is replaced with a service
part.)
(*1): Feed amount counted in the information mode
To Next Page
