Toshiba B-EX4 SERIES Service Manual

5. SYSTEM MODE EO18-33027
5.3 DIAG
5-20
5.3.2 AUTO DIAGNOSTICS
The printing procedure of “AUTO DIAGNOSTIC” of “DIAG.” is same as 5.3.1 MAINTENANCE CONT.
The many layer from top menu of system mode to AUTO DIAGNOSTICS is below.
MENU ITEM
SYSTEM MODE
<1>DIAG.
AUTO DIAGNOSTIC
PRINT TYPE
TRANSFER
DIRECT
CUT TYPE
OFF
ON
CHECKING & PRINT
When an error occurs while printing, the error message is displayed, the ERROR LED turns on, and the
ONLINE LED turns off. Though the error can be cleared by presing [ENTER], [CANCEL] or [MODE] key,
the printer does not print the erroneous label.
NOTE:
For the B-EX4D2, the direct thermal mode (DIRECT) has been set as default, it is not necessary to select
the print type. Even if the thermal transfer mode (TRANSFER) is selected, it will be automatically
changed to the direct thermal mode when the [ENTER] key is pressed.

Toshiba B-EX4 SERIES Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
Max Print Width	104 mm
Connectivity	USB, Serial, Ethernet
Media Sensor	Transmissive, Reflective
Media Type	Roll, Fanfold, Tag, Ticket
Media Width	25.4 mm
Ribbon Width	110 mm
Ribbon Length	Up to 600 m
Media Thickness	0.06 – 0.19 mm
