10. RFID ANALYZE TOOL EO18-33027
10.1 System Requirement
10- 1
10. RFID ANALYZE TOOL
When an RFID module is installed, the printer will be able to write data on an RFID tag as well as print data
on the surface of the RFID-tag embedded label.
To properly issue RFID tags, it may be necessary to adjust the RFID tag position so that it stops just above
the antenna of the RFID module.
A proper adjustment value is obtained by using RFID Analyze Tool. It is different depending on the
following conditions.
• RFID tag type
• The shape of RFID tag antenna
• Position of RFID tag embedded in RFID tag supply
• Variation of RFID module
The RFID Analyze Tool enables discovering an optimum tag position and output power of the RFID module
for data read/write.
An adjustment value is stored in the printer memory by using a PC command or “UHF setting” parameter in
the system mode (Section 5.11.4.)
10.1 System Requirement
System
IBM Compatible PC running Windows 2000 or Windows XP
Installed memory 16MB minimum (32M byte recommended)
Available hard disk space of 10M byte ore more
NOTE: Windows 2000 and Windows XP are registered trademarks of Microsoft Corporation.
Interface
Connect the printer to a PC with an RS-232C (Serial) interface or LAN interface.
Download
RFID Analyze Tool is downloadable from the following web site.
http://barcode.toshibatec.co.jp/Ris/products/barcode/support/en/index.php
