6. ON LINE MODE EO18-33027
6. 8 INFORMATION MODE
6-20
6.8.2 Information Mode Operation Example
[Online mode]
1. Normal state
↓ Press [PAUSE] key.
[Online mode]
2. Pause state
↓ Hold down [UP] key for 3 seconds.
[Information mode]
3. Feed amount is
displayed.
Press [CANCEL] key to
return to 1. Normal state.
↓ Press [ENTER] key.
[Online mode]
4. Printing is performed.
After printing is finished, the
display returns to 1. Normal
state.
(Supplementary Explanation)
(1) When printing is performed in this mode, a quick reset is performed.
Performing a quick reset causes the print count (number of labels issued) to be reset to zero and the
image buffer to be cleared. When the automatic calibration is enabled, a calibration is performed
after the quick reset.
When the automatic call at power on parameter is enabled in the Saved data call command, saved
data will be called after a quick reset.
(2) Previous print conditions are applied to the printing performed in this mode, except:
Printing direction
When the mirror printing has been specified, only the mirror printing is not performed. Therefore, the
bottom first mirror printing and top first mirror printing will be changed to bottom first printing and top
first printing, respectively.
Effective print width and X-coordinate fine adjustment
When the feed amount to be printed reaches the max. number of digits, the print position will be
determined as follows:
Print position
Applicable model
B-EX4T1 The feed amount at the max. number of digits (25 mm) is
center-aligned.
B-EX4T1-G/T-QM/CN C1.1A
The feed amount at the max. number of digits (74 mm) is
center-aligned.
B-EX4T1-G/T-QM/CN C1.3 or later
B-EX4T2/4D2 The feed amount at the max. number of digits (25 mm) is
left-aligned.
B-EX4T2-G/T-QM/CN C1.1
B-EX4D2-G/T-QM/CN D1.1
The feed amount at the max. number of digits (74 mm) is
left-aligned.
B-EX4T2-G/T-QM/CN C1.2A or later
B-EX4T2-H-QM/CN C1.1A or later
B-EX4D2-G/T-QM/CN D1.2 or later
