Toshiba B-EX4 SERIES Service Manual

6. ON LINE MODE EO18-33027
6. 8 INFORMATION MODE
6-22
B-EX4T2/4D2: Max. number of digits: 74 mm, Left-aligned
<Applicable model> B--EX4T2-G/T-QM/CN C1.2A or later, B-EX4T2-H-QM/CN C1.1A or later,
B-EX4D2-G/T-QM/CN D1.2 or later
<Print data 2>
Item
Information
Range
1st line
Title
TOTAL COUNTER LIST
2nd line
Date and time
*1
MM: Month
01 to 12
dd: Day
01 to 31
yyyy: Year
2000 to 2099
hh: Hour
00 to 23
mm: Minute
00 to 59
3rd line
Model
B-EX4T1-QM/CN 203 dpi
B-EX4T1-G
B-EX4T1-QM/CN 305 dpi
B-EX4T1-T
B-EX4T2-QM/CN 203 dpi
B-EX4T2-G
B-EX4T2-QM/CN 300 dpi
B-EX4T2-T
B-EX4T2-QM/CN 600 dpi
B-EX4T2-H
B-EX4D2-QM/CN 203 dpi
B-EX4D2-G
B-EX4D2-QM/CN 300 dpi
B-EX4D2-T
4th line
Serial number *2
11 to 32-digit half-size alpha-numeric
(A to Z, a to z, 0 to 9, space, hyphen
5th line
Feed amount in information mode (unit:
cm)
0 to 320000000
6th line
Feed amount in information mode (unit:
inch)
0 to 125984251.9
*1: When an optional real time clock is not installed, data areas in this line will be blank.
(E.g.) “ - - : “
*2: In the case a serial number has never been registered to the printer, MAC address of wired LAN
is printed without delimiters. If the MAC address of wired LAN cannot be obtained (refer to
Section 5.3.2 AUTO SELF-DIAGNOSIS PRINTOUT), this line will be blank.
TOTAL COUNTER LIST
MM-dd-yyyy hh:mm
xxxxxxxxxxxxxxxx
S/N:zzzzzzzzzzzzzzzzzzzzzzzzzzzzzzzz
PRINTER aaaaaaaaacm
bbbbbbbbb.binch
Max. number of digits: 74 mm
Effective print width

Toshiba B-EX4 SERIES Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
Max Print Width	104 mm
Connectivity	USB, Serial, Ethernet
Media Sensor	Transmissive, Reflective
Media Type	Roll, Fanfold, Tag, Ticket
Media Width	25.4 mm
Ribbon Width	110 mm
Ribbon Length	Up to 600 m
Media Thickness	0.06 – 0.19 mm
