9. MAJOR UNIT REPLACEMENT EO18-33027

9.10 PINCH ROLLER UPPER ASS’Y

9-23

5) Release the two springs to remove the pinch roller upper ass’y.

6) Replace the pinch roller upper ass’y with a new one, then reassemble in the reverse order of

removal.

Spring

Pinch Roller Upper Ass’y
