1. UNPACKING EO18-33027

1.1 PROCEDURE

1- 2

5) Open the top cover and remove the five pieces of tape. And then, open the ribbon shaft holder

plate to remove the ribbon shaft pad from the printer.

Top Cover

Ribbon Shaft Holder Plate

Ribbon Shaft Pad

Tape

OPEN
