6.5.1.3 Configurable submodule-related F-parameters (F_Par)
Safety-related parameters are defined with the F-Parameters of the safety-related submodule
Position (BP) and Position (XP). The secure transmission of F-Parameters requires a CRC
calculation, see Chapter 6.8.10 on Page 136.
The F-Parameter can be set according to the following table via an input box in the configuration tool
and are automatically sent by the control to the measuring system during start-up via the record data
object with index 0x0002.
Malfunctions which are caused by improper parameterization result in the
danger of death, serious physical injury and/or damage to property!
 The system manufacturer must ensure proper functioning by carrying
out a protected test run during commissioning and whenever
parameters have been changed.
Parameter
BP
XP
Description
F_Check_iPar
X
X
NoCheck: No check
F_SIL
X
X
SIL1, SIL2, SIL3, no SIL
F_CRC_Length
X
–
3-Byte-CRC
–
X
4-Byte-CRC
F_CRC_Seed
–
X
CRC-Seed32
F_Passivation
–
X
Device/Module
F_Block_ID
X
X
1: uses F_iPar_CRC: requires F_iPar_CRC
F_Par_Version
X
X
1: V2 mode
F_Source_Add
X
X
1: Source address = 1
Range: 1-65534
F_Dest_Add
X
X
1: Destination address = 1
Range: 1-65534
F_WD_Time
X
X
125 ms: Watchdog time = 125
Range: 10-10000 ms
F_Par_CRC
X
–
9296: CRC of F-parameters = 9296
Range: 0-65535
–
X
35282: CRC of F-parameters = 35282
Range: 0-65535
F_iPar_CRC
X
X
3489011925: CRC iParameter = 3489011925
Range: 0-4294967295
________________________________
X: applicable
–: not applicable
Centralized and detailed description of the F-parameters,
see Chapter 6.8 from Page 135.
