6.7.2 Safe Control (BP/XP)
Unsigned8
Bit
Function
BP
XP
0
iPar_EN
iParameter assignment unlocked
X
X
1
OA_Req
Operator confirmation request required (re-integration)
X
X
2
R_cons_nr
Reset the virtual serial number counter
X
X
3
reserved
X
-
Use_TO2
The second watchdog F_WD_Time_2 is used
-
X
4
activate_FV
Activate fail-safe values
X
X
5
Toggle_h
Toggle-Bit
X
X
6
reserved
X
-
ChF_Ack
Operator confirmation request required after channel error handled
-
X
7
reserved
X
-
Loop check
Reserved for loop-back verification (“1”)
-
X
A more detailed description of the control bits can be found in the PNO document
“PROFIsafe – Profile for Safety Technology on PROFIBUS DP and PROFINET IO”,
Order No.: 3.192b.
