1 General information
This interface-specific user manual contains the following topics:
● Safety instructions
● Installation
● Commissioning
● Configuration / Parameterization
● Troubleshooting and diagnostic options
Since it has a modular structure, this User Manual is supplementary to other documentations, such as
product data sheets, dimensional drawings, brochures, the Safety Manual, etc.
The User Manual may be included in the customer’s specific delivery package or it may be requested
separately.
1.1 Applicability
This User Manual applies exclusively to measuring system series according to the following keys for
article numbers and types with PROFINET IO interface and PROFIsafe profile:
Article number
* 1
* 2
* 3
* 4
* 5
-
* 6
* 6
* 6
* 6
* 6
Position
Designation
Description
* 1
A
Explosion protection enclosure (ATEX);
C
Absolute encoder, programmable
* 2
D
Redundant dual scanning unit
* 3
V
Solid shaft
H
Hollow shaft
S
Blind shaft
* 4
582
Outer diameter  58 mm, Generation 2
* 5
M
Multi-turn
S
Singleturn
* 6
-
Consecutive number
* = placeholder
Type key
See Revision Lists:
CD_582M +FS02: www.tr-electronic.de/f/TR-ECE-TI-D-0343
CD_582M +FS03: www.tr-electronic.de/f/TR-ECE-TI-D-0349
The products are labeled with affixed nameplates and are components of a system.
The following documentation therefore also applies:
● See the Chapter “Other Applicable Documents” in the Safety Manual
www.tr-electronic.de/f/TR-ECE-BA-GB-0142
● Product data sheets https://www.tr-electronic.com/s/S020955
