6.6.1.1.6 Output Preset Multi-Turn / Preset Single-Turn
Integer16
Bit
Register
Description
2
0
…2
15
Preset Multi-Turn
Preset-Wert, Multi-Turn - share
Integer16
Bit
Register
Description
2
0
…2
15
Preset Single-Turn
Preset value, Single-Turn – share
The desired preset value must be in the range of 0 to 268 435 455 (28 bits). On this basis, the
corresponding values for Preset Multi-Turn/Preset Single-Turn can be calculated along with
the resolution of the measuring system, the max. number of steps per revolution as specified on the
nameplate (8192):
Number of revolutions = desired preset value / steps per revolution
The integer content from this division results in the number of revolutions and must be entered in the
Preset Multi-Turn register.
Single-turn position = desired preset value – (steps per revolution * no. of revolutions)
The result of this calculation must be entered in the Preset Single-Turn register.
The preset value is set as new position when the preset adjustment function is executed; see chapter
“Preset adjustment function” on Page 130.
