6.2.3.7 Preset affects XIST1
Alternatively, this parameter can also be set during operation via an acyclic parameter access to the
function control PNU 65004 Bit 2, see Page 61.
The preset function, see Page 61, is applied to the position
output in G1_XIST1, if the parameter Encoder Class 4
functionality is set to enable.
The preset function has no effect on the position output in
G1_XIST1.
6.2.3.8 Scaling function control
Alternatively, this parameter can also be set during operation via an acyclic parameter access to the
function control PNU 65004 Bit 3, see Page 61.
Scaling function control switched off
The scaling function control with the parameters Scaling:
Measuring units per revolution and Scaling:
Total measuring range is applied if the parameter
Encoder Class 4 functionality is set to enable.
6.2.3.9 Alarm channel control (V3.1)
Also see Chapter “Diagnostic alarm”on Page 71.
This parameter is only supported in compatibility mode V3.1. In standard mode V4.2, the
profile-specific control via the alarm channel is always active.
Alternatively, this parameter can also be set during operation via an acyclic parameter access to the
function control PNU 65004 Bit 4, see Page 61.
The profile-specific diagnosis is switched off if the parameter
V3.1 compatibility mode is set to enable. Only the
communication-specific alarms are sent via the alarm
channel.
The profile-specific diagnosis is turned on if the parameter
V3.1 compatibility mode is set to enable. The
measuring-system-specific alarm channel is transmitted as a
channel-related control. This means that the data volume to
be transferred can be limited in synchronous mode.
