Parameterization and configuration
 TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 60 of 154 TR - ECE - BA - GB - 0139 - 02 11/21/2019
6.2.4.2.6 Supported warnings (PNU 65001.05)
The parameter in Subindex 5 displays the warnings supported by the measuring system.
Bits
Definition
= 0
=1
0 - 13
-
Not supported
-
14
Preset value out of range
-
Supported
15
Command not supported
-
Supported
16 - 24
-
Not supported
-
25 - 31
reserved
6.2.4.2.7 Encoder Profile Version (PNU 65001.06)
The parameter in Subindex 6 contains the profile version implemented in the measuring system.
Bits
Definition
0 - 7
0x02 (LSB)
Versions no. 0x0402
8 - 15
0x04 (MSB)
16 - 31
0x0000, reserved
6.2.4.2.8 Offset value 32-bit (PNU 65001.08)
The offset value in Subindex 8 is calculated internally during execution of the preset function and
offsets the actual position value by the calculated value. Each time the preset function is executed, the
re-calculated value is specified as a scaled value according to the set resolution.
Integer32, complement on two
Byte
X+0
X+1
X+2
X+3
Bit
31-24
23-16
15-8
7-0
Data
2
31
– 2
24
2
23
– 2
16
2
15
– 2
8
2
7
– 2
0
6.2.4.2.9 Measuring units per revolution (PNU 65001.09)
The parameter in Subindex 9 contains the set number of steps/revolution, see Chapter
“Scaling parameter”on page 48.
Unsigned32
Byte
X+0
X+1
X+2
X+3
Bit
31-24
23-16
15-8
7-0
Data
2
31
– 2
24
2
23
– 2
16
2
15
– 2
8
2
7
– 2
0
6.2.4.2.10 Total measuring range (PNU 65001.10)
The parameter in Subindex 10 contains the set Measuring range in steps, see Chapter
“Scaling parameter”on page 48.
Unsigned32
Byte
X+0
X+1
X+2
X+3
Bit
31-24
23-16
15-8
7-0
Data
2
31
– 2
24
2
23
– 2
16
2
15
– 2
8
2
7
– 2
0
