6.2.4.1 Preset value 32-bit (PNU 65000)
The zero point of the measuring system can be adapted to the mechanical zero point via this
parameter and is set either as an absolute value or as a relative value, in relation to the position
output, during execution of the preset function, see Chapter “Preset function” on Page 70. A sample
procedure for adjusting the value is shown in Chapter 6.2.4 from Page 53.
The transmitted value is interpreted differently, depending on the preset mode set:
Preset mode = absolute
 Transmitted value is interpreted as an Unsigned32 type
Preset mode = relative
 Transmitted value is interpreted as an Integer32 type in two's complement form
PNU
65000
Meaning
Preset value
Data type
Integer32
Access
read/write
Activation
with write access
Storage
PNU 971
Default value
0
Integer32
Byte
X+0
X+1
X+2
X+3
Bit
31-24
23-16
15-8
7-0
Data
2
31
– 2
24
2
23
– 2
16
2
15
– 2
8
2
7
– 2
0
6.2.4.2 Operating status (PNU 65001)
The parameter structure can only be read and contains all status information for the measuring
system.
PNU
65001
Meaning
Encoder Operating Status
Data type
Array[n] Unsigned32
Access
read
Subindex
Meaning
Page
0
Block Header
58
1
Operating status
58
2
Error
59
3
Supported errors
59
4
Warnings
59
5
Warnings supported
60
Continued on next page
