9.6 Information & Maintenance
9.6.1 I&M0 – I&M4
The measuring system supports the following I&M functions (I&M RECORDS):
● I&M0, Record Index = 0xAFF0
● I&M1, Record Index = 0xAFF1
● I&M2, Record Index = 0xAFF2
● I&M3, Record Index = 0xAFF3
● I&M4, Record Index = 0xAFF4
according to PROFIBUSPROFINETProfile Guidelines Part 1, order no. 3.502.
I&M functions specify how the device-specific data, according to a type plate, must be uniformly stored
in the IO device.
The I&M record can be addressed via an acyclic read or write command and must be sent with the
corresponding record index to Module 1 / Submodule 1 of the measuring system.
I&M0, Record Index = 0xAFF0 (read only):
Contents
Number of Bytes (60)
Block
Header
Block Type = 0x0020 (I&M0)
2
Block Length
2
Block Version, High-Byte
1
Block Version, Low-Byte
1
Manufacturer ID
2
Order no.
20
Serial No.
16
Hardware Revision
2
Software Revision
4
Revision Status
2
Profile ID
2
Profile-specific type
2
I&M Version
2
I&M Support
2
