Troubleshooting and diagnostic options
 TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 150 of 154 TR - ECE - BA - GB - 0139 - 02 11/21/2019
I&M1, Record Index = 0xAFF1 (write/read):
Contents
Number of Bytes (60)
Block Header
Block Type = 0x0021 (I&M1)
2
Block Length
2
Block Version, High-Byte
1
Block Version, Low-Byte
1
IM_Tag_Funktion (VisibleString)
Unique identifier for the function/task
32
IM_Tag_Position (VisibleString)
Unique identifier for the location
22
I&M2, Record Index = 0xAFF2 (write/read):
Contents
Number of Bytes (22)
Block Header
Block Type = 0x0022 (I&M2)
2
Block Length
2
Block Version, High-Byte
1
Block Version, Low-Byte
1
IM_Datum (VisibleString)
Date/time of installation or commissioning:
Format: YYYY-MM-DD´T´HH:MM (ISO 8601)
16
I&M3, Record Index = 0xAFF3 (write/read):
Contents
Number of Bytes (60)
Block Header
Block Type = 0x0023 (I&M3)
2
Block Length
2
Block Version, High-Byte
1
Block Version, Low-Byte
1
IM_Kommentar (VisibleString)
Additional information or comments
54
I&M4, Record Index = 0xAFF4 (write/read):
Contents
Number of Bytes (60)
Block Header
Block Type = 0x0024 (I&M4)
2
Block Length
2
Block Version, High-Byte
1
Block Version, Low-Byte
1
IM_Signatur (VisibleString)
Signature
54
