6.2.4.7.3 Telegram selection (PNU 922)
Use this parameter to read out the preselected telegram (81-84), see Chapter 6.2.1 on Page 35.
PNU
922
Meaning
Telegram selection
Data type
Unsigned16
Access
read
Value
Definition
81
Standard Telegram 81
82
Standard Telegram 82
83
Standard Telegram 83
84
Standard Telegram 84
6.2.4.7.4 Tolerated master sign-of-life faults (PNU 925)
The max. number of permissible errors of the master sign-of-life counter is defined with this
parameter, see also Chapter 6.2.3.12 on Page 49.
PNU
925
Meaning
Tolerated master sign-of-life faults
Data type
Unsigned16
Access
read/write
Activation
with write access
6.2.4.7.5 Device identification (PNU 964)
This parameter contains all information needed to identify the PROFINET measuring system in the
network.
PNU
964
Meaning
Device identification
Data type
Array [n] Unsigned16
Access
read
Subindex
Meaning
0
Manufacturer Vendor Code: 0x0153 (TR-Electronic GmbH)
1
Device type: 0x0404
2
Current Software Version: 101 (decimal) = Version 1.0.1 (example)
3
Firmware Date (Year): YYYY (decimal)
4
Firmware date: (Day/Month): ddmm (decimal)
