Parameterization and configuration
TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 80 of 154 TR - ECE - BA - GB - 0139 - 02 11/21/2019
6.3.3.4.1 Scaling: Measuring units per revolution
Defines how many steps the measuring system outputs during one revolution of the measuring
system shaft.
8192 steps per revolution
6.3.3.4.2 Scaling: Total measuring range
Defines the total number of steps (measuring range in steps) of the measuring system, before the
measuring system starts at 0 again.
The actual upper limit value to be entered for the measuring range in steps depends on the measuring
system design and can be calculated using the formula below. As the value "0" is already counted as
a step, the end value = measuring range in steps - 1.
Measuring range in steps = steps per revolution * number of revolutions
For the purposes of calculation, the parameters Steps/Revolution and Number of Revolutions can
be taken from the measuring system nameplate.
When entering parameter data, ensure that the parameters “Measuring range in
steps” and “Number of steps per revolution” are selected such that the quotient
of the two parameters is a power of 2.
