6.2.4.2.3 Error (PNU 65001.02)
The parameter in Subindex 2 displays the current measuring system errors. When an error occurs,
the corresponding bit is set. The measuring system remains in the error state until the cause of the
error has been eliminated and the error state has been acknowledged with the control word G1_STW
Bit 15 = 0->1 edge.
In case of a scaling error, check if the parameter Total measuring range is an integer and a
multiple of the parameter Measuring units per revolution, see also chapter 6.2.3.11 as from
page 48.
If the error cannot be acknowledged, an attempt can be made to execute a device RESET via
PNU 972. If the error still cannot be deleted after this measure, the measuring system must be
replaced.
Bits
Definition
= 0
=1
0
Position error
no
yes
1 - 5
Not supported
Always 0
-
6
Scaling error
no
yes
7 - 10
Not supported
Always 0
-
11
Sign-of-life faults
no
yes
12 - 24
Not supported
Always 0
-
25 - 31
reserved
6.2.4.2.4 Supported errors (PNU 65001.03)
The parameter in Subindex 3 displays the errors supported by the measuring system.
Bits
Definition
= 0
=1
0
Position error
-
Supported
1 - 5
-
Not supported
-
6
Scaling error
-
Supported
7 - 10
-
Not supported
-
11
Sign-of-life faults
-
Supported
12 - 24
-
Not supported
-
25 - 31
reserved
6.2.4.2.5 Warnings (PNU 65001.04)
The parameter in Subindex 4 displays the current measuring system warnings.
Bits
Definition
= 0
=1
0 - 13
-
Always 0
-
14
Preset value out of range
The transmitted preset value is not
executed and must be overwritten by a
valid value.
no
yes
15
Command not supported
no
yes
16 - 24
-
Always 0
-
25 - 31
reserved
