5 Resetting the device parameters
The measuring system may be destroyed or damaged or its function be
impaired by penetration of foreign bodies and ingress of moisture!
Firmly close the access to the address switches with the screw plug
after the settings have been made.
Use the two HEX rotary switches SW1 and SW2 for resetting the device parameters. The position and
assignment of the HEX rotary switches can be found in the accompanying pin assignment.
Procedure:
1. Unscrew the screw plug
2. Switch SW1 / SW2 = 0
3. Wait 3 s
4. Switch SW2 = 5 / SW1 = 2, corresponds to 0x52 = “R” (RESET)
5. Wait 3 s, green NET status LED flashes at 2 Hz
6. Switch SW1 / SW2 = 0
7. Preset, scaling offset and parameterization are reset, the device name is deleted (“…”), and the IP
address and subnet mask are set to 0.0.0.0
8. The measuring system reboots to apply the settings
9. The process is complete, and the screw plug can be screwed back in again
