6.3.1.1 Standard Telegram 36 (BP/XP)
Basic Protocol (BP)
Structure of input words 1 to 4, IO device -> Master
IW 1
IW 2
IW 3
IW 4
Safe Status, 3-Byte-CRC (V2.4)
S_ZSW1_ENC
S_NIST16
S_XIST32
F_MessageTrailer4Byte
Structure of output words 1 to 3, Master -> IO device
OW 1
OW 2
OW 3
Safe Control, 3-Byte-CRC (V2.4)
S_STW1_ENC
S_PRESET32
F_MessageTrailer4Byte
Expanded Protocol (XP)
Structure of input words 1 to 4, IO device -> Master
IW 1
IW 2
IW 3
IW 4
Safe Status, 4-Byte-CRC (V2.6.1)
S_ZSW1_ENC
S_NIST16
S_XIST32
F_MessageTrailer5Byte
Structure of output words 1 to 3, Master -> IO device
OW 1
OW 2
OW 3
Safe Control, 4-Byte-CRC (V2.6.1)
S_STW1_ENC
S_PRESET32
F_MessageTrailer5Byte
6.3.1.2 Standard Telegram 37 (BP/XP)
Basic Protocol (BP)
Structure of input words 1 to 3, IO device -> Master
IW 1
IW 2
IW 3
Safe Status, 3-Byte-CRC (V2.4)
S_ZSW1_ENC
S_XIST32
F_MessageTrailer4Byte
Structure of output words 1 to 3, Master -> IO device
OW 1
OW 2
OW 3
Safe Control, 3-Byte-CRC (V2.4)
S_STW1_ENC
S_PRESET32
F_MessageTrailer4Byte
Expanded Protocol (XP)
Structure of input words 1 to 3, IO device -> Master
IW 1
IW 2
IW 3
Safe Status, 4-Byte-CRC (V2.6.1)
S_ZSW1_ENC
S_XIST32
F_MessageTrailer5Byte
Structure of output words 1 to 3, Master -> IO device
OW 1
OW 2
OW 3
Safe Control, 4-Byte-CRC (V2.6.1)
S_STW1_ENC
S_PRESET32
F_MessageTrailer5Byte
