6.3.3.5 Velocity value normalization
Selection
Value
Description
Default
Steps/sec
0
The speed in signal S_NIST16 is output in steps
per second.
Steps/100 msec
1
The speed in signal S_NIST16 is output in steps
per 100 ms.
Steps/10 msec
2
The speed in signal S_NIST16 is output in steps
per 10 ms.
Revolutions per minute
3
The speed in signal S_NIST16 is output in
revolutions per minute.
X
6.3.3.6 Window increments (internal, not visible)
This parameter defines the maximum permissible position deviation in increments of the master /
slave scanning systems integrated in the measuring system. The permissible tolerance window is
internally set to 1000 increments and can not be changed. The position deviation in increments is
always based on the non-scaled resolution of 13 bits = 8192 steps/revolution.
