Printed in the Federal Republic of Germany TR-Electronic GmbH 2019, All Rights Reserved
11/21/2019 TR - ECE - BA - GB - 0139 - 02 Page 27 of 154
4 Commissioning
4.1 PROFINET IO
Important commissioning information can be found in the PROFINET Directive:
● PROFINET Commissioning Guidelines, Order No.: 8.082
This and more information on PROFINET or PROFIsafe is available from the offices of the PROFIBUS
User Organization:
PROFIBUS Nutzerorganisation e.V.,
Haid-und-Neu-Str. 7,
D-76131 Karlsruhe,
www.profibus.com/
www.profisafe.net/
Tel.: ++ 49 (0) 721 / 96 58 590
Fax: ++ 49 (0) 721 / 96 58 589
e-mail: mailto:germany@profibus.com
4.1.1 Device classes
The following device classes are used in a PROFINET IO system:
● IO controller
For example a PLC, which addresses the connected IO device.
● IO device
Distributed field device (measuring system), which is assigned to one or more IO controllers and
also transmits alarms in addition to the process and configuration data.
● IO supervisor (Engineering Station)
A programming device or industrial PC, which has access to all process and parameter data in
parallel with the IO controller.
4.1.2 Device description file (XML)
The GSDML file and the associated bitmap file are part of the measuring system.
Download
www.tr-electronic.de/f/TR-ECE-ID-MUL-0058
