6.5.3.2.8 Window increments
This parameter defines the maximum permissible position deviation in increments of the master /
slave scanning systems integrated in the measuring system. The permissible tolerance window is
basically dependent on the maximum speed occurring in the system and must first be determined by
the system operator. Higher speeds require a larger tolerance window. Values are within a range of
50…4000 increments. Standard value = 1000 increments.
The larger the window increments, the larger the angle until an error will be detected.
The position deviation in increments is always based on the non-scaled resolution of
13 bits = 8192 steps/revolution.
