Parameterization and configuration
 TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 112 of 154 TR - ECE - BA - GB - 0139 - 02 11/21/2019
MEASURING RANGE
Defines the total number of steps of the measuring system, before the measuring system starts at 0
again.
Lower limit
2 steps
Upper limit
536 870 912 steps (30 bits)
Default
536870912
The actual upper limit value to be entered for the measuring range in steps depends on the
measuring system design and can be calculated using the formula below. As the value "0" is already
counted as a step, the end value = measuring range in steps - 1.
Measuring range = steps per revolution * number of revolutions
For the purposes of calculation, the parameters Steps/Revolution and Number of Revolutions can
be taken from the measuring system nameplate.
REVOLUTIONS NUMERATOR / REVOLUTIONS DENOMINATOR
These two parameters together define the number of revolutions, before the measuring system
starts at 0 again.
As decimal numbers are not always finite (such as 3.4), but may have an infinite number of digits after
the decimal point (such as 3.43535355358774...) the number of revolutions is entered as a fraction.
Numerator lower limit
1
Numerator upper limit
256000
Default numerator
65536
Denominator lower limit
1
Denominator upper limit
16384
Denominator default
1
Formula for gearbox calculation:
Measuring range in steps = number of steps per revolution *
Number of numerator revolutions
Number of denominator revolutions
If it is not possible to enter parameter data in the permitted ranges of numerator and denominator, the
attempt must be made to reduce these accordingly. If this is not possible, it may only be possible to
represent the relevant decimal number approximately. The resulting minor inaccuracy accumulates for
real round axis applications (infinite applications with motion in one direction).
A solution is e.g. to perform adjustment after each revolution or to adapt the mechanics or gear ratio
accordingly.
The parameter Number of steps per revolution may also be a decimal number, however the
measuring range may not. The result of the above formula must be rounded up or down. The
resulting error is distributed over the total number of revolutions programmed and is therefore
negligible.
