TR-Electronic CDV582 - Page 146

Troubleshooting and diagnostic options
 TR-Electronic GmbH 2019, All Rights Reserved Printed in the Federal Republic of Germany
Page 146 of 154 TR - ECE - BA - GB - 0139 - 02 11/21/2019
Continued
Error type
Diagnostic message / Meaning
Solution
F:8203
d
Process – configuration
Error during initialization of the
application's configuration data from
configuration memory.
- Contact Product Support.
F:8204
d
Processor unit – memory
The internal hardware diagnostics has
detected a internal memory fault.
- A system restart is required.
- Contact Product Support if the
problems persist after a system restart.
W1:8205
d
Sequence - parameter check
The device parameterization is faulty.
- Check all device configuration
parameters -> transfer correct
parameters.
F:8206
d
Processor unit - program sequence
The device is in fail-safe state.
- A system restart is required.
F:8207
d
MT sampling unit - gear unit
The device is in fail-safe state.
- Contact Product Support if the
problems persist after a system restart.
W2:8208
d
Sequence - remote channel
- The remote channel overwrites the
current process data value of the
measurement channel.
W2:8209
d
Power supply unit – undervoltage
The internal hardware diagnostics has
detected an undervoltage in the internal
power supply unit.
- Contact Product Support if problems
persist.
W2:8210
d
Power supply unit – overvoltage
The internal hardware diagnostics has
detected an overvoltage in the internal
power supply unit.
- Contact Product Support if problems
persist.
W1:8211
d
Sequence – scaling
The internal hardware diagnostics has
detected a shaft movement out of range in
switched off state.
- Verify the correctness of the
transmitted process data. A preset
adjustment must be performed in order
to acknowlege the error.
F:8212
d
Sequence - FSCP communication
The device is in fail-safe state.
- A system restart is required.
F:8213
d
Processor unit – reset
Error of the processor-internal hardware
diagnostics.
- A system restart is required.
F:8214
d
Processor unit - remote channel
The device is in fail-safe state.
- A system restart or an error
acknowledgement is required.
F:16384
d
Interface – fieldbus
The hardware diagnostics of the fieldbus
interface has detected an internal error.
- A system restart is required.
