iST
AR eX Connections
iST
AR eX Installation and Configuration Guide
4–19
The connection is through S1, which is
factory
preset, as shown in Table
4.1.
PMB Connections
Figure
4.12 shows the iSTAR eX-PMB connections.
T
able 4.1:
RS-485 Direction Switch for
COM1 and COM2
Off
On
S1-1
Read1 to COM2.
Read1 to COM1. (Default)
S1-2
Read2 to COM2.
Read2 to COM1. (Default)
S1-3
Read3 to COM2. (Default)
Read3 to COM1.
S1-4
Read4 to COM2. (Default)
Read4 to COM1.
104
106
