Tyco iSTAR eX - Chapter 7: Using the LCD Diagnostic Display

iSTAR eX Installation and Configuration Guide 7–1
7
The iSTAR eX includes an LCD message display. For normal operations,
configure the LCD to display status messages. For troubleshooting
operations, configure the LCD to display diagnostic messages about readers,
card data, inputs, outputs, network ports and devices.
In This Chapter
 Setting the LCD Message Display ................................................................................. 7-2
 Displaying Status Messages ........................................................................................... 7-3
 iSTAR eX Diagnostic Tests.............................................................................................. 7-4
Using the LCD
Diagnostic Display
NOTE
The iSTAR eX LCD display and associated diagnostic tests have not been
evaluated by UL.
